ASME B16.5 Lap joint flange dimensions, Manufacturer of Carbon Steel Lap Joint Flange in Mumbai, India.
ASME B16.5 Lap Joint Flange
Stainless Steel Lap Joint Flange
Carbon Steel Lap Joint Flange
Steel Mart India is oldest Stainless Steel Lap joint Flange manufacturers in India. We are supplying Lap Joint Pipe Flange, ASME B16.47 Lap Joint Flange, 2 inch lap joint flange & Lap Joint Backing Flange at affordable price due to reasonable man hours in India and large source of high quality Lap Joint Pipe Flanges at best price available in Mumbai, India. Are you looking for Lap Joint Flange With Stub End contact us for same, Check Lap Joint Flange Dimensions and Lap Joint Flange Weight Chart to buy Lap Joint Flange Welding. We have different Lap Joint Flange Types and they are easy for Installation Also. View Lap Joint Flange Stub End Dimensions.
Steel Mart India is prominent manufacturer of Copper Nickel Lap Joint Flange approved by Saudi Aramco. We are largest stockist of MSS SP-44 Lap Joint Flange. Steel Mart India is a distributor of complete range of ANSI 150# Lap Joint Flange, ANSI B16.5 Class 150 Lap Joint Flange in various sizes.
If you are looking to purchase high quality CS Lap joint flange at best price in India, check our price of Flat Face Lap Joint Flange including 30 inch lap joint flange, Flat face lap joint flange and A105 lap joint flange.
Steel Mart India is one of the leading Supplier of Stainless Steel Lap joint Flange to Turkey, Malaysia, Bahrain, Oman, Qatar, Russia, Thailand, Singapore,Canada, UAE, Egypt, Indonesia, USA, Kuwait, Iran, France, Australia, UK, Israel, Sweden, Germany, Italy, Sri Lanka & Saudi Arabia.
We are largest stockist of MSS SP-44 Lap Joint Flange at best price as we are one of the largest supplier & trader of Carbon Steel Lap Joint Flange in India. We have our stocking distributors in Delhi, Bangalore, Surat, (Gujarat), Hyderabad, Pune (Maharashtra) & Chennai in Tamil Nadu. Check once our ANSI B16.5 Lap Joint Flange price before buying RTJ Lap Joint Flange from India or China. also mail for our live stock of Carbon Steel Lap Joint Flange to check types & sizes with our ready stock we can give you best price of Copper nickel lap joint flange.
You can mail to sales@steelmarts.com for ASME B16.5 Lap Joint Flange to get reasonable cost
We can also provide free sample of Raised Face Lap Joint Flange, Steel Mart India is having our Dealer & Distributor in Delhi, Aurangabad, Ghaziabad, West-Bengal, Bhosari, Rajasthan, Gurgaon, Kolkata, Tamil Nadu, Khopoli, Punjab, Faridabad, Pune, Madhya Pradesh, Raipur, Maharashtra, Kolhapur, Jaipur, Ludhiana, Chennai (Madras), Gujarat, Indore, Ahmedabad, Rajkot, Nagpur, Vadodara, Karnataka,Bangalore, Uttar-Pradesh, Karnataka, Chhattisgarh, Haryana. So if you are looking for best price of AWWA C207 A105 Lap Joint Flange or ASME B16.47 Series b Lap Joint Flange, ASME B16.5 Class 600 Lap Joint Flange near you with shortest time delivery or free sample of ASME B16.5 Lap Joint Flange. Call us or mail to sales@steelmarts.com for Latest & Updated price List of Stainless Steel Lap joint Flange and Lap Joint Weld Flange. Our dealer near you will contact you and will provide full information about Class 150 Lap Joint Flange. Steel Mart India is looking for more stockholders in Africa, Europe, Middle East, Far East Asia to sell our BS 4504 PN10 Loose flange. So mail to sales@steelmarts.com to become our authorised dealer & distributor of EN 1092-2 PN16 Lap Joint Flange in your country.
Contact Us for Latest Price List of Raised Face Lap Joint Flange, EN 1092-2 PN16 Lap Joint Flange manufacturer in India, Check Flat Face Lap Joint Flange Dimensions
Table of Content
Stainless Steel Lap joint Flange Manufacturers
ASME B16.5 Lap joint flange can be achieved by two methods. When the pipe material is exotic the “lap” is formed by shaping the pipe material after the loose flange has been fitted. If the piping material is readily weldable a “lap” end can be butt welded to the pipe. A105 Lap joint Flange are very useful for non-metallic piping and components. Most materials are much better in compression than in tension. The Stainless Steel Lap joint Flange is held in compression by the loose flange which is in tension due to the bolt load.
| Lap joint flange type | Lap joint flange Price in India | Lap joint flange Price in USD | Lap joint flange Price in UAE Dirham |
|---|---|---|---|
| A350LF2 2 LAP JOINT 300 FLANGE | INR 2,020 / Unit | USD $ 28.57 /Unit | UAE Dirham 104.94 |
| A105N 1 1/2 LAP JOINT 300 FLANGE A105N 1 1/2AP JOINT 300 | INR 1,197 / Unit | USD $ 16.93 / Unit | UAE Dirham 62.18 |
| INC.825 2 LAP JOINT 1500 FLANGE INC 825 2 LAP JOINT 1500 | INR 1,039 / Unit | USD $ 14.69 / Unit | UAE Dirham 53.97 |
| F316L 2 LAP JOINT 1500 FLANGE F316 L 2 LAP JOINT 1500 | INR 892 / Unit | USD $ 12.62 /Unit | UAE Dirham 46.34 |
| A105N 2 LAP JOINT 300 | INR 3,450 / Unit | USD $ 48.80 /Unit | UAE Dirham 179.23 |
| ASME B16.5 Lap Joint Flange Size Chart | 1/2" (15 NB) to 48" (1200NB) DN10~DN5000 |
|---|---|
| Lap Joint Pipe Flanges Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| RTJ Lap Joint Flange Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS Lap Joint Stub End Flanges |
| RF Lap Joint Flange Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 RTJ Lap Joint Flange |
| JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K RF Lap Joint Flange |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar Lap Joint Pipe Flanges |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar Lap Joint Ring Flange |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized Stainless Steel Lap Joint Flange |
| Most common types of Lap Joint Weld Flange | Forged / Threaded / Screwed / Plate |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production technique |
|
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design |
As per your drawing
AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Origin | Indian / West Europe / Japan / USA / Korean |
| Manufacturer of |
ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc.
|
| Lap Joint Pipe Flanges Uses & application |
|
| Export to | Ireland, Singapore, Indonesia, Ukraine, Saudi Arabia, Spain, Canada, USA, Brazil, Thailand, Korea, Iran, India, Egypt, Oman, Dubai, Peru, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
- Carbon Steel Lap Joint Stub End Flanges
- A105 Lap Joint Flange
- Alloy Steel High-Temp RF Lap Joint Flange
- A182 Gr F1 Lap Joint Pipe Flanges
- A182 Gr F11 RTJ Lap Joint Flange
- A182 Gr F12 Lap Joint Stub End Flanges
- A182 Gr F22 Lap Joint Flange
- A182 Gr F5 Lap Joint Weld Flange
- A182 Gr F9 RF Lap Joint Flange
- Alloy Steel Low-Temp
Lap Joint Ring Flange
- A350 Gr LF2 RTJ Lap Joint Flange
- A350 Gr LF3 Lap Joint Flange
- Austenitic Stainless Steel Lap Joint Flange
- A182 Gr F304 Lap Joint Ring Flange
- A182 Gr F316 RF Lap Joint Flange
- A182 Gr F321 RTJ Lap Joint Flange
- A182 Gr F347 Lap Joint Flange
- A182 Gr F304L Lap Joint Pipe Flanges
- A182 Gr F316L Lap Joint Stub End Flanges
- A182 Gr F317 RF Lap Joint Flange
- A182 Gr F317L RTJ Lap Joint Flange
- A182 Gr F321 Lap Joint Pipe Flanges
- A182 Gr F310 Lap Joint Weld Flange
- A182 Gr 347 Lap Joint Flange
- Nickel Alloy RTJ Lap Joint Flange
- ASTM B564 Lap Joint Weld Flange
- astm b564 uns n06600 RTJ Lap Joint Flange
- astm b564 uns n06625 Lap Joint Ring Flange
- astm b564 uns no4400 RF Lap Joint Flange
- astm b564 uns n08810 RTJ Lap Joint Flange
- astm b564 uns n08811 Lap Joint Pipe Flanges
- astm b564 uns n08825 Lap Joint Flange
- astm b564 uns n04400 RF Lap Joint Flange
- astm b564 uns n10276 Lap Joint Stub End Flanges
- astm b564 uns n10665 Lap Joint Weld Flange
- Titanium
Lap Joint Ring Flange
- astm b381 grade f2 Lap Joint Weld Flange
- astm b381 f5 Lap Joint Stub End Flanges
- astm b381 f3 Lap Joint Flange
- astm b381 f12 RF Lap Joint Flange
- astm b381 f7 RTJ Lap Joint Flange
- Other grades: ASTM B381 F1, F2, F2H, F3, F4, F5, F6, F7, F7H, F9, F10, F11, F12, F13, F14, F15, F16, F16H, F17, F18, F19, F20, F21, F23, F24, F25, F26 , F26H, F27, F28, F29, F30, F31, F32, F33, F34, F35, F36, F37, F38 Lap Joint Pipe Flanges
| Nominal Pipe Size | Outside Diameter (O) | Thickness (T) | Length Thru Hub (Y) | Hub Diameter (X) | Radius (r) | Bore (B) | Bolt Circle (C) | Number of Holes | Diameter of Holes |
|---|---|---|---|---|---|---|---|---|---|
| 1/2 | 3.50 | 0.44 | 0.63 | 1.19 | 0.13 | 0.90 | 2.38 | 4 | 0.63 |
| 3/4 | 3.88 | 0.50 | 0.63 | 1.50 | 0.13 | 1.11 | 2.75 | 4 | 0.63 |
| 1 | 4.25 | 0.56 | 0.69 | 1.94 | 0.13 | 1.38 | 3.13 | 4 | 0.63 |
| 1 1/4 | 4.63 | 0.63 | 0.81 | 2.31 | 0.19 | 1.72 | 3.50 | 4 | 0.63 |
| 1 1/2 | 5.00 | 0.69 | 0.88 | 2.56 | 0.25 | 1.97 | 3.88 | 4 | 0.63 |
| 2 | 6.00 | 0.75 | 1.00 | 3.06 | 0.31 | 2.46 | 4.75 | 4 | 0.75 |
| 2 1/2 | 7.00 | 0.88 | 1.13 | 3.56 | 0.31 | 2.97 | 5.50 | 4 | 0.75 |
| 3 | 7.50 | 0.94 | 1.19 | 4.25 | 0.38 | 3.60 | 6.00 | 4 | 0.75 |
| 3 1/2 | 8.50 | 0.94 | 1.25 | 4.81 | 0.38 | 4.10 | 7.00 | 8 | 0.75 |
| 4 | 9.00 | 0.94 | 1.31 | 5.31 | 0.44 | 4.60 | 7.50 | 8 | 0.75 |
| 5 | 10.00 | 0.94 | 1.44 | 6.44 | 0.44 | 5.69 | 8.50 | 8 | 0.88 |
| 6 | 11.00 | 1.00 | 1.56 | 7.56 | 0.50 | 6.75 | 9.50 | 8 | 0.88 |
| 8 | 13.50 | 1.13 | 1.75 | 9.69 | 0.50 | 8.75 | 11.75 | 8 | 0.88 |
| 10 | 16.00 | 1.19 | 1.94 | 12.00 | 0.50 | 10.92 | 14.25 | 12 | 1.00 |
| 12 | 19.00 | 1.25 | 2.19 | 14.38 | 0.50 | 12.92 | 17.00 | 12 | 1.00 |
| 14 | 21.00 | 1.38 | 3.13 | 15.75 | 0.50 | 14.18 | 18.75 | 12 | 1.13 |
| 16 | 23.50 | 1.44 | 3.44 | 18.00 | 0.50 | 16.19 | 21.25 | 16 | 1.13 |
| 18 | 25.00 | 1.56 | 2.88 | 19.88 | 0.50 | 18.2 | 22.75 | 16 | 1.25 |
| 20 | 27.50 | 1.69 | 4.06 | 22.00 | 0.50 | 20.25 | 25.00 | 20 | 1.25 |
| 22 | 29.50 | 1.81 | 4.25 | 24.25 | 0.50 | 22.25 | 27.25 | 20 | 1.38 |
| 24 | 32.00 | 1.88 | 4.38 | 26.13 | 0.50 | 24.25 | 29.50 | 20 | 1.38 |
|
NPS
(Inches) |
DN
(mm) |
FLANGE OD
A MM |
FLANGE THICKNESS D
MM |
SLIP ON FLANGE WEIGHT (KGS) | WELD NECK FLANGE WEIGHT (KGS) | BLIND FLANGE WEIGHT (KGS) |
| 1/ 2 | 15 | 88.9 | 11.2 | 0.4 | 0.5 | 0.4 |
| 3/ 4 | 20 | 98.6 | 12.7 | 0.6 | 0.7 | 0.6 |
| 1 | 25 | 108 | 14.2 | 0.8 | 1 | 0.9 |
| 1 1/ 4 | 32 | 117.3 | 15.7 | 1 | 1.3 | 1.2 |
| 1 1/ 2 | 40 | 127 | 17.5 | 1.3 | 1.7 | 1.5 |
| 2 | 50 | 152.4 | 19.1 | 2.1 | 2.6 | 2.4 |
| 2 1/ 2 | 65 | 177.8 | 22.4 | 3.3 | 4.1 | 3.9 |
| 3 | 80 | 190.5 | 23.9 | 3.9 | 4.9 | 4.9 |
| 3 1/ 2 | 90 | 215.9 | 23.9 | 4.8 | 6.1 | 6.2 |
| 4 | 100 | 228.6 | 23.9 | 5.3 | 6.8 | 7.0 |
| 5 | 125 | 254 | 23.9 | 6.1 | 8.6 | 8.6 |
| 6 | 150 | 279.4 | 25.4 | 7.5 | 10.6 | 11.3 |
| 8 | 200 | 342.9 | 28.4 | 12.1 | 17.6 | 19.6 |
| 10 | 250 | 406.4 | 30.2 | 16.5 | 24 | 28.6 |
| 12 | 300 | 482.6 | 31.8 | 26.2 | 36.5 | 43.2 |
| 14 | 350 | 533.4 | 35.1 | 34.6 | 48.4 | 58.1 |
| 16 | 400 | 596.9 | 36.6 | 44.8 | 60.6 | 76.1 |
| 18 | 450 | 635 | 39.6 | 48.9 | 68.3 | 93.7 |
| 20 | 500 | 698.5 | 42.9 | 61.9 | 84.5 | 122.0 |
| 24 | 600 | 812.8 | 47.8 | 86.9 | 115 | 185.0 |
ASME B16.47 Series b Type A Lap Joint Flange Supplier in Mumbai, ASME B16.5 Lap Joint Flange, DIN 86029 PN10 Ductile Iron Lap Joint Flange stockholder, View ASME B16.5 Class 600 Lap Joint Flange Price List in Mumbai, Stainless Steel Lap Joint Flange stockist in UAE.
Get free quote for Lap Joint Backing Flange in Mumbai, ANSI B16.5 A105 LJ Flange, Lap Joint Flange N06022 for Raised Face connection Exporter in India, We are one of the oldes Large Diameter Lap Joint Flange Supplier in Mumbai. ANSI B16.5 Class 150 Carbon Steel Lap Joint Flange exporter in India
